Compromise Bars

Our Mission

Supply quality US origin and manufactured steel railroad products, provide innovative engineered products and address issues by presenting railroad engineered based solutions.

Forged 6-Hole Compromise Joint Bars With Re-enforced Bar Center

115# to 136# X 36 In. Forged 6-Hole Compromise Joint Bar With Re-enforced Bar Center

Compromise bars are made with US forged Microalloy steel. The center of the bars have a unique
2-1/2″ X 2-3/4″ steel re-enforcement providing added strength. Bars are 36” long with six-holes and are
handed. Compromise bars are milled on CNC machine with center of tool coolant and lubrication cutter to
standard or any diameter hole and spacing that is specified, eliminating the need for field rail cutting and
drilling when end rail hole patterns are different from the compromise bar. This process reduces the effect of

heat stressing the bars which is prevalent when heating and punching holes.

——

  • 115RE to 136RE Forged Compromise Joint Bars
    STOCK ITEM
  • Forged115RE to 136RE forged compromise joint bars
    are manufactured with Microalloyed steel that meets
    AREMA Standard strength properties.
  • Compromise Joint Bars meets all “Buy America”
    requirements.
  • The manufacturing process utilizes the use of CNC
    machines to mill bolt holes, the highest quality method,
    producing the least residual stress in the compromise
    joint bars. Custom milling holes available.
  • Compromise joint bars are Off-Set (Handed).

To Order Call 844-205-1219 or e-mail:
 tchambers@associatedrailproducts.com

Manufactured Compromise Bars

  • Made from US Railroad Grade Steel
  • 6-Hole, 5-Hole & 4-Hole Availability
  • Meet AREMA Standards and
    Available Handed & Centerline

Holes Milled on CNC Machine with center tool cutter with lubricant & coolant
